GENERAL INFORMATION
00-00–5
00-00
Body Dimensions (Flat-plane Dimensions)
• Flat-plane dimensions are the dimensions measured by projecting certain reference points onto a plane
surface.
810
{31.89}
FLAT-PLANE DIMENSIONS
FRONT FENDER INSTALLATION NUT
acxuub00000033
