BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–28
Removal Procedure
1. Drill the 1 location indicated by (A) shown in the figure.
Note
x Drill the 1 location indicated by (A) from the interior.
2. Drill the 13 location indicated by (B) shown in the figure.
(A)1
(B) 1
(B) 4
(B) 5
(B) 3
FRONT SIDE FRAME COMPONENT
am6zzb0000006
7)$HOࡍࠫ㧞㧜㧜㧥ᐕ㧣㧞㧞ᣣޓ᳓ᦐᣣޓඦ೨㧝㧝ᤨ㧠㧟ಽ
To Next Page
