BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–29
09-80B
3. Rough cut area indicated by (C) shown in the figure.
Caution
x During rough cutting, be careful not to damage the front side frame (rear).
4. Drill the 1 location indicated by (D) shown in the figure.
5. Remove the front side frame.
End Of Sie
(D) 1
(C)
am6zzb0000016
