Mazda 6 2009 - Cabin Side Frame Straight-Line Dimensions [Dimensions]

BODY STRUCTURE [DIMENSIONS]
09-80D–8
End Of Sie
BM: CABIN SIDE FRAME
CABIN SIDE FRAME STRAIGHT-LINE DIMENSIONS [DIMENSIONS]
id098010743600
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A Cowl panel installation hole φ8 {0.3}
B
LH:Wiring harness installation
hole
RH:Front fender stay
installation hole
φ7 {0.3}
C
Shroud side member datum
hole
φ7 {0.3}
D
Front bumper reinforcement
installation hole
φ10 {0.39}
E
Front bumper reinforcement
installation hole
φ10 {0.39}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A
B
C
D
E
H
F
G
L
J
I
O
P
N
M
K
1,408 {55.43}
1,390 {54.72}
1,084 {42.68}
1,093 {43.03}
944 {37.17}
1,228 {48.35}
1,836 {72.28}
1,167 {45.94}
1,211 {47.68}
1,271 {50.04}
1,150
{45.28}
1,107
{43.58}
1,191
{46.89}
RH:907 {35.71}
LH:841 {33.11}
RH:1,031 {40.59}
LH:966 {38.03}
763
{30.04}
A
B
C
D
E
H
F
G
L
J
I
O
P
N
M
K
1,324 {52.13}
1,691 {64.41}
1,226 {48.27}
1,742 {68.58}
1,643 {64.69}
1,159 {45.63}
985 {38.78}
994 {39.13}
895 {35.24}
652 {25.67}
791
{31.14}
RH:907 {35.71}
LH:841 {33.11}
RH:950 {37.40}
LH:885 {34.84}
mm {in}
