BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–3
09-80B
Removal Procedure
1. Grind the 2 locations indicated by (A) shown in the figure.
2. Grind the 5 locations indicated by (B) shown in the figure.
3. Remove the front bumper bracket.
End Of Sie
(B)2
(B)1
(A)2
(B)2
FRONT BUMPER BRACKET
am6xub0000001
