BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–32
FRONT SIDE FRAME (PARTIAL CUTTING) REMOVAL [PANEL REPLACEMENT]
id098008742100
Symbol Mark
Removal Procedure
RH
Caution
x The rough cut area indicates the maximum size range of the installation position.
1. Rough cut area (A), drill the 18 locations indicated by (B), and then remove the front side frame.
SYMBOL MARK
MEANING
SPOT WELDING
ROUGH CUT LOCATION
am6xub0000003
