BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–31
09-80B
6. Plug weld the 1 location indicated by (C) shown in the figure.
Note
x Plug weld the 1 location indicated by (C) from the interior.
7. Plug weld the 13 locations indicated by (D) shown in the figure.
End Of Sie
(C)1
(D) 1
(D) 4
(D) 5
(D) 3
FRONT SIDE FRAME COMPONENT
am6zzb0000007
