BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–8
3. Drill the 7 locations indicated shown in the figure.
4. Remove the shroud side member.
End Of Sie
SHROUD SIDE MEMBER
2
2
3
am6xub0000001
