BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–88
6. Plug weld the 6 locations indicated by (A), then install the spare tire bracket.
7. Plug weld the 114 locations indicated by (B) shown in the figure.
(B)5
(B)4
(B)4
(B)31
(B)20
(B)4
(B)14
(B)14
(B)9
(B)9
(A)6
REAR FLOOR PAN
am6xub0000005
