BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–10
6. Plug weld the 6 locations indicated shown in the figure.
End Of Sie
BM: COWL SIDE REINFORCEMENT
FRONT FENDER BRACKET
6
am6xub0000001
7)$HOࡍ࡯ࠫ㧞㧜㧜㧥ᐕ㧣᦬㧞㧞ᣣޓ᳓ᦐᣣޓඦ೨㧝㧝ᤨ㧠㧟ಽ
