Page 14
Functional Principle, Technical Data
optoNCDT 1402
Technical Data3.3
Model ILD 1402-5 1402-10 1402-20 1402-50 1402-100 1402-200 1402-250VT 1402-600
Measurement range mm 5 10 20 50 100 200 250 600
Start of range mm 20 20 30 45 50 60 100 200
Midrange mm 22.5 25 40 70 100 160 225 500
End of range mm 25 30 50 95 150 260 350 800
Linearity
µm 5 ... 9 5 ... 18 7 ... 36 12 ... 90 20 ...180 40 ... 360 50 ... 1200 120 ... 3000
0.18 % FSO 0.5 % FSO
Resolution
static, µm
0.6 1 2 5 10 20 50 120
0.01 % FSO
1
0.02 % FSO
1
dynamic, µm
1.5 kHz
1 ... 3 2 ... 5 5 ... 10 6 ... 25 12 ... 50 13 ... 100 32 ... 300 80 ... 600
0.02 ... 0.05 % FSO 0.02 ... 0.12 % FSO
Measurement rate, programmable: 1.5 kHz; 1 kHz; 750 Hz; 375 Hz; 50 Hz
Light source Semiconductor laser 1 mW, 670 nm (red)
Laser class Class 2 (II) acc. to DIN EN 60825-1: 2007
Spot diameter
SMR, µm 110 110 210 1100 1400 2300 5000 2,6 x 5 mm
MR, µm 380 650 530 110 130 2200 5000 2,6 x 5 mm
EMR, µm 650 1200 830 1100 1400 2100 5000 2,6 x 5 mm
Protection class IP 67
Vibration 15 g / 10 Hz ... 1 kHz 20 g / 10 Hz ... 1 kHz
Shock 15 g / 6 ms (IEC 68-2-29)
Weight, without cable approx. 83 g approx. 130 g
Temperature stability 0.03 % FSO/°C 0.08 % FSO/°C
Operation temperature 0 ... 50 °C
Storage temperature -20 °C ... 70 °C
Measurement value
output
analog 4 ... 20 mA (1 ... 5 V with cable PC 1402-3/U) or
digital RS422
