MICRO-EPSILON ILD1402-5 User Manual

Page 68
Serial Interface RS422
optoNCDT 1402
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF2 0x00 0x02 0xA0F20002
0x20 0x20 0x0D 0x0A 0x20200D0A
Request Data Protocol8.3.26
Name: GET_CI_MODE
Description: Requests the state of the sensors command interpreter.
Format: 31 24 23 16 15 8 7 0 hex
„-“ „-“ „-“ „R“ 0x2D2D2D52
Reply: 31 24 23 16 15 8 7 0 hex
„-“ „-“ „-“ „1“ 0x2D2D2D31
„4“ „C“ „I“ 0x0X 0x3443490X
Options for X:
X = 1, the command interpreter of the sensor operates with the ILD1401 data protocol. Note: The sensor
uses a different protocol!
X = 2, the command interpreter of the sensor operates with the ILD1402 data protocol.
