Available Cables
optoNCDT 1402
Available Cables17.
i
All cables are high flex and can be used in cabel drag chains.
Type Cable length Characteristics
PC1402- 3/I,
PC1402-6/I,
PC1402-8/I
3 m
6 m
8 m
Interface und supply cable for current output, one end of the
cable has a molded M12 female connector, the other end has
free leads with ferrules.
PC1402-3/U,
PC1402-6/U,
PC1402-8/U
3 m
6 m
8 m
Interface und supply cable for voltage output (250 Ohm load,
U
out
= 1 … 5 V), one end of the cable has a molded M12 female
connector, the other end has free leads with ferrules.
PC1402-3/USB,
PC1402-6/USB
3 m
6 m
With integrated RS422 / USB - converter, one end of the cable
has a molded M12 female connector, the other end an USB
connector for PC; power supply unit for 90 .. 235 VAC included;
Software for easy sensor commissioning.
PC1402-3/D-SUB/9pol,
PC1402-8/D-SUB/9pol
3 m
8 m
Power and output cable, one end of the cable has a molded
M12 female connector, the other end a 9 pol D-SUB for RS422/
USB converter and open leads; a RS422/USB converter is not
enclosed.
Disconnect or connect the D-sub connection between RS422
and USB converter when the sensor is disconnected from
power supply only.
PC1402-3/CSP,
PC1402-8/CSP,
PC1402-10/CSP
3 m
8 m
10 m
Connecting cable with straight connector on both sides to con-
nect an ILD1402 sensor to a CSP2008.
PC1402-3/IF2008,
PC1402-6/IF2008,
PC1402-8/IF2008
3 m
6 m
8 m
Connecting cable, one end of the cable has a molded M12 fe-one end of the cable has a molded M12 fe-
male connector, the other end a D-SUB to connect an ILD1402
sensor to an IF2008 PCI interface card.
PC1401/1402-0,2 0.2 m Patch cable, 12 pol to 7 pol.
