Page 67
Serial Interface RS422
optoNCDT 1402
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xFA 0x00 0x02 0xA0FA0002
0x20 0x20 0x0D 0x0A 0x20200D0A
Data Protocol ILD14018.3.25
Name: SET_CIMODE_1401
Description: Switches the sensor into the ILD1401 data protocol.
The sensor replies with the ILD1402 data protocol, after sending the reply the sensor switches the data proto-
col.
The following parameters can be changed in the ILD1401 data protocol:
Digital or analog data output -
Behavior in case of an error -
Averaging -
The other parameters remain fixed:
Baud rate: 38400 -
Measurement rate: 1000 Hz -
Type of digital output: binary -
Mode of analog/digital output: continuous -
Key status: auto lock -
Mode of save setting: save at each time -
Mode of external input: as teach in -
Teach value 1: 0.00 resp. taught value T1 remains -
Teach value 2: 16368.00 resp. taught value T2 remains -
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF2 0x00 0x02 0x20F20002
