MICRO-EPSILON ILD1402-5 User Manual

Page 58
Serial Interface RS422
optoNCDT 1402
Input for Scaling and Trigger 8.3.14
Name: SET_EXT_INPUT_MODE
Description: Defines the function of the switching input “Teach in“ (Pin 9 on the sensor connector).
Parameter:
X = 0 --> external input operates as scaling input -
X = 1 --> external input operates as trigger controlled input for the data output -
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF8 0x00 0x03 0x20F80003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF8 0x00 0x02 0xA0F80002
0x20 0x20 0x0D 0x0A 0x20200D0A
Peak Detection with Video Signal 8.3.15
Name: SET_PEAKSEARCHING
Description: Specifies the search algorithm.
Parameter:
X = 0 --> peak with global maximum -
X = 1 --> first peak, direction pixel 0 up to pixel 127, left to right -
X = 2 --> last peak, direction pixel 0 up to pixel 127, left to right -
Default setting:
Scaling
