Serial Interface RS422
optoNCDT 1402
Overview8.3.2
Information command
0x20490002 GET_INFO Shows sensor data
0x204A0002 GET_SETTINGS Shows sensor settings
Average
0x207F0004 SET_AV Sets average type and value
Measurement value output
0x20760002 DAT_OUT_OFF Stops measurement value output
0x20770002 DAT_OUT_ON Permanent measurement value output
0x20F40003 SET_OUTPUTMODE Output mode
0x20F50003 SET_OUTPUTTIME_MS Output time in ms
Switch output settings
0x20900003 SET_OUTPUT_CHANNEL Output: current or RS422
Speed
0x20800003 SET_BAUDRATE 115.2 / 57.6 / 38.4 / 19.2 / 9.6 kBaud
0x20850003 SET_SCANRATE Measurement rate: 1.5 kHz; 1.0 kHz; 750 Hz; 375 Hz
Error output (analog output)
0x20810003 SET_ANALOG_ERROR_HANDLER Behavior of the analog output in the case of an error
External input
0x20F80003 SET_EXT_INPUT_MODE Scaling, triggering
Switching off the laser (external)
0x20870002 LASER_ON Switches the laser on
0x20860002 LASER_OFF Switches the laser off
Measurement value data format
0x20880003 ASCII_OUTPUT Options: ASCII / Binary
Key lock
0x20600003 SET_KEYLOCK Key enabled / locked / auto lock
Reset
0x20F10002 SET_DEFAULT Reset to default factory settings
0x20F00002 RESET_BOOT Reboot the sensor
