Measurement Value Output
optoNCDT 1402
Digital Value Output 7.2
Data Protocol ILD14017.2.1
The digital measurement values are issued as unsigned digital values (raw values).
Digital value Used for
0 ... 39 SMR back-up
40 ... 4055 Measurement range
4056 ... 4095 EMR back-up
Calculation of a measurement value in mm from digital output:
Reference value Start of Measuring Range: Reference value Midrange
x [mm] = (digital
OUT
* - 0.01) * MR [mm]
1.02
4096
x [mm] = (digital
OUT
* - 0.51) * MR [mm]
1.02
4096
Example: MR =10 mm, digital value = 2048, measurement value = 5 mm or 0 mm
Note: A digital value can be calculated from a measurement value (millimeter) as follows:
digital = + 0.01 *
OUT
x [mm]
MR [mm]
4096
1.02
Data Protocol ILD14027.2.2
The digital measurement values are issued as unsigned digital values (raw values).
Digital value Used for Digital value Used for
0 ... 16367 Value range 16208 ... 16367 EMR back-up (1 %)
0 ... 160 SMR back-up (1 %) 16370 ... 16383 Error codes
161 ... 16207 Measurement range
