Page 57
Serial Interface RS422
optoNCDT 1402
Set Measurement Rate 8.3.13
Name: SET_SCANRATE
Beschreibung: Sets the measurement rate [Hz].
Parameter:
X = 0 --> 1500 - X = 3 --> 375 -
X = 1 --> 1000 - X = 4 --> 50 -
X = 2 --> 750 -
Procedure: The sensor replies and then re-boots. The string of the boot message contains “CI140x“, “CR“
“LF“ and the answer of “GET_INFO“.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x85 0x00 0x03 0x20850003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x85 0x00 0x02 0xA0850002
0x20 0x20 0x0D 0x0A 0x20200D0A
Default setting:
1500 Hz
