MICRO-EPSILON ILD1402-5 User Manual

Page 65
Serial Interface RS422
optoNCDT 1402
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF1 0x00 0x02 0xA0F10002
0x20 0x20 0x0D 0x0A 0x20200D0A
Save Settings in RAM or FLASH8.3.22
Name: SET_SAVE_SETTINGS_MODE
Description: Saves the transmitted settings into the RAM or the FLASH.
Parameter:
X = 0 --> transmitted new settings are stored in the RAM and valid until power off. -
X = 1 --> transmitted new settings are stored in the FLASH and are thus are generally valid. -
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF7 0x00 0x03 0x20F70002
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF7 0x00 0x02 0xA0F70002
0x20 0x20 0x0D 0x0A 0x20200D0A
Default setting:
Save in FLASH
