Page 59
Serial Interface RS422
optoNCDT 1402
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xFB 0x00 0x03 0x20FB0003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xFB 0x00 0x02 0xA0FB0002
0x20 0x20 0x0D 0x0A 0x20200D0A
A peak inside the video signal is limited by overrun and subsequent shortfall the threshold limit. Several valid
peaks are evaluated when measuring glass. Measurements on metal surfaces can also produce multiple
peaks. Determine the valid peaks in the software tool (video signal).
Search Threshold8.3.16
Name: SET_THRESHOLD
Description: Defines the characteristics of the search threshold.
Parameter:
X = 0 --> lower than standard -
X = 1 --> Standard -
X = 2 --> higher than standard -
X = 3 --> highest -
i
Changing the threshold from factory default (standard) may influence linearity and resolution.
Modify the sensor only with specific materials as with semitransparent plastics and so educate the sen-
sor recently.
