Page 64
Serial Interface RS422
optoNCDT 1402
Set Default Setting 8.3.21
Name: SET_DEFAULT
Description: Resets the set parameters to the default settings (factory settings).
This concerns:
Data protocol ILD1401 -
Output channel: 0 --> analog output,
Analog error handler: 1 --> in the case of an error: 3.75 mA on the analog output,
Filter: 0 = Median off,
Data protocol ILD1402 -
Output channel: 0 --> analog output,
Teach value 1 --> 0.0
Teach value 2 --> 16368.0
Analog error handler: 1 --> in the case of an error: 3.75 mA on the analog output,
Average type: 0 --> moving average,
Average value: 1 --> no averaging,
Measurement rate: 0 --> 1500 Hz,
Baud rate: 0 --> 115200 Baud,
Digital output type: 0 --> binary,
Analog digital output mode: 0 --> continuous,
Output time --> 500 ms,
Key lock: 2 --> key locked automatically after 5 min power on,
Save settings mode: 1 --> transmitted new settings are stored in the FLASH,
External input type: 0 --> external input for scaling
Procedure: The sensor replies and then re-boots. The string of the boot message contains “CI140x“, “CR“
“LF“ and the answer of “GET_INFO“.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF1 0x00 0x02 0x20F10002
