MICRO-EPSILON ILD1402-5 User Manual

Page 60
Serial Interface RS422
optoNCDT 1402
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xFC 0x00 0x03 0x20FC0003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xFC 0x00 0x02 0xA0FC0002
0x20 0x20 0x0D 0x0A 0x20200D0A
Switching off the Laser (External)8.3.17
Name: LASER_OFF
Description: Switches off the laser. This command is volatile e.g. the laser is on after power on.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x86 0x00 0x02 0x20860002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x86 0x00 0x02 0xA0860002
0x20 0x20 0x0D 0x0A 0x20200D0A
i
The command LASER_OFF is volatile. This means that the laser is switched on again if the power sup-
ply was switched off or the sensor was rebooted by means of the RESET_BOOT command and pin 8 is
connected with GND.
