MICRO-EPSILON ILD1402-5 User Manual

Page 42
Serial Interface RS422
optoNCDT 1402
Reply Byte 1 Byte 2 Byte 3 Byte 4 Byte 5
„I“ „L“ 0x81 0x00 none
Command error-free
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5
“I“ “L“ 0xC1 0x01 Error code
Faulty command
Data Protocol ILD14028.2.9
Name: SET_CIMODE_1402
Description: Switches the sensor into the ILD1402 data protocol. The sensor replies with the ILD1401 data
protocol, after sending the reply the sensor switches to the mode and maintains a reset.
Format Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9
“+” “+” “+” 0x0D „I“ „L“ 0x11 0x01 none
Reply Byte 1 Byte 2 Byte 3 Byte 4 Byte 5
„I“ „L“ 0x91 0x00 none
Command error-free
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5
“I“ “L“ 0xD1 0x01 Fehlercode
Faulty command
