Serial Interface RS422
optoNCDT 1402
Reset Sensor8.3.20
Name: RESET_BOOT
Description: Starts the sensor’s initialization phase. Duration about 900 ms.
Procedure: The sensor replies and then re-boots. The string of the boot message contains “CI140x“, “CR“
“LF“ and the answer of “GET_INFO“.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF0 0x00 0x02 0x20F00002
Antwort: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF0 0x00 0x02 0xA0F00002
0x20 0x20 0x0D 0x0A 0x20200D0A
