MICRO-EPSILON ILD1402-5 User Manual

Page 66
Serial Interface RS422
optoNCDT 1402
Scaling Values for the Analog Output8.3.23
Name: SET_TEACH_VALUE
Description: Sets the scaling values.
Parameter:
Teach value 1, XXXXXXXX --> 0.0 up to 16368.0 -
Teach value 2, XXXXXXXX --> 0.0 up to 16368.0 -
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF9 0x00 0x04 0x20F90004
0xXX 0xXX 0xXX 0xXX 0xXXXXXXXX
0xXX 0xXX 0xXX 0xXX 0xXXXXXXXX
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF9 0x00 0x02 0xA0F90002
0x20 0x20 0x0D 0x0A 0x20200D0A
Reset Scaling Values for the Analog Output8.3.24
Name: RESET_TEACH_VALUE
Description: Resets the scaling values.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xFA 0x00 0x02 0x20FA0002
Default setting:
Teach value 1: 0.0
Teach value 2: 16368.0
