MICRO-EPSILON ILD1402-5 User Manual

Page 51
Serial Interface RS422
optoNCDT 1402
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x7F 0x00 0x04 0x207F0004
0x00 0x00 0x00 0x0X 0x0000000X
0x00 0x00 0x00 0xXX 0x000000XX
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x7F 0x00 0x02 0xA07F0002
0x20 0x20 0x0D 0x0A 0x20200D0A
Stopping the Measurement Value Output8.3.6
Name: DAT_OUT_OFF
Description: Switches off the digital output for the measurement values. This has no effect on communica-
tion with the sensor via the digital interface. This command has a higher priority in trigger mode. The com-
mand is volatile. Therefore data out is on after power on.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x76 0x00 0x02 0x20760002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x76 0x00 0x02 0xA0760002
0x20 0x20 0x0D 0x0A 0x20200D0A
