MICRO-EPSILON ILD1402-5 User Manual

Page 53
Serial Interface RS422
optoNCDT 1402
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x90 0x00 0x02 0xA0900002
0x20 0x20 0x0D 0x0A 0x20200D0A
Characteristics for Digital or Analog Data Output 8.3.9
Name: SET_OUTPUTMODE
Description: Sets the output characteristics.
X = 0 --> - continuously each measurement, depending on baud rate and the measuring frequency;
delay = (Bit quantity / Baud rate) * measuring frequency [Hz], if delay < 0, delay = delay +1)
delay = number of cycles with no serial output
X = 1 --> time-based, see Chap. 8.3.10. -
X = 2 --> trigger controlled, see Chap. 8.3.14 -
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF4 0x00 0x03 0x20F40003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF4 0x00 0x02 0xA0F40002
0x20 0x20 0x0D 0x0A 0x20200D0A
Default setting:
continuously
