Serial Interface RS422
optoNCDT 1402
Name: LASER_ON
Description: Switches on the laser
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x87 0x00 0x02 0x20870002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x87 0x00 0x02 0xA0870002
0x20 0x20 0x0D 0x0A 0x20200D0A
i
The command LASER_ON is effective only if pin 8 is connected with GND.
Change Data Format8.3.18
Name: ASCII_OUTPUT
Description: Switches the data format for the measurement value output via the digital interface. The com-
mand replies will remain unaffected.
Parameter:
X = 0 --> Binary output (2 Byte) -
X = 1 --> ASCII output (6 Byte) -
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x88 0x00 0x03 0x20880003
0x00 0x00 0x00 0x0X 0x0000000X
Default setting:
Binary format
