Page 46
Serial Interface RS422
optoNCDT 1402
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x49 0x00 0xxx 0xA04900xx
Info string is a readable ASCII character string:
ILD 1402: Standard
A/N: 4120154
O/N: 000
S/N: 1234570
MR: 50
SoftVer: 1.001.796
BootVer: 1.001.16
Date: 09/01/23
Out Channel: analog | digital
Analog Error: last value | error value | error value after cycles xx //xx is 2 up to 99
Filter Type: moving average | median
Filter Number: xx //with moving average xx is 1 up to 128, with median xx is 7, 5, 7 or 9
Scanrate: xxHz //xx is 1500 Hz, 1000 Hz, 750 Hz, 375 Hz
type of digital output: binary | ascii
mode of analog/digital output: continuous | time | trigger
output time: xx //xx is time in ms
1
key status: unlock | lock | auto lock
mode of save setting: no save | save at each time
mode of extern input: as teach in | as output trigger
peak searching: global maximum | first peak | last peak
Teach value 1: xx //(xx is 1.0 up to 16368.0
Teach value 2: xx //xx is 1.0 up to 16368.0
0x20 0x20 0x0D 0x0A 0x20200D0A
| = separates variants from each other
// = beginning of a comment
1) Output time is available only, if ”mode of analog/digital output“ is set to ”time”
