Serial Interface RS422
optoNCDT 1402
Reading the Software Version8.2.4
Name: VERSION
Description: The sensor transmitts the software version.
Format Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9
“+” “+” “+” 0x0D „I“ „L“ 0x09 0x00 none
Reply Byte 1 Byte 2 Byte 3 Byte 4 Byte 5
„I“ „L“ 0x89 Quantity Info string
Command error-free
Byte 1 Byte 2 Byte 3 Byte 4
“I“ “L“ 0x89 0x07
Version is a readable ASCII string: 1.001
Faulty command Byte 1 Byte 2 Byte 3 Byte 4 Byte 5
“I“ “L“ 0xC9 0x01 Error code
Average On/Off8.2.5
Name: MEDIAN
Description: Switches between „Averaging on“ and „Averaging off“. The median is generated from a preset
number of measurement values. Here the inputted measurement values (3 measurement values) are resorted
after each measurement. The average value is then outputted as the median. When the median is gener-
ated in the controller only 3 measurement values are taken into account, i.e. a 0 median is not possible. This
means that individual interference pulses can be suppressed. The measurement value curve is not smoothed
to a great extent.
Byte 9 = 0; Median off
Byte 9 = 1; Median on
Default setting:
Median off
