Page 48
Serial Interface RS422
optoNCDT 1402
Save settings mode
0 = transmitted settings are stored in the RAM and are valid until power off -
1 = transmitted settings are stored in the FLASH and are valid, even after power off/on -
External input type
0 = external input is used for scaling -
1 = external input is used as trigger input (trigger controlled output) -
Peak searching
0 = peak with global maximum -
1 = first peak, direction pixel 0 up to pixel 127, left to right -
2 = last peak, direction pixel 0 up to pixel 127, left to right -
Threshold
0 = lower than standard -
1 = standard -
2 = higher than standard -
3 = highest -
Measuring range [mm]
XXX X = 1 ...65535 -
Reserved 1
Reserved 2
Reserved 3
Reserved 4
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x4A 0x00 0x02 0x204A0002
