The numbering of the individual inputs and outputs is structured as follows: The first number refers to the device and the
second to the port (for example AI2.3: Analog input from PIF No. 2 and Port No. 3).
On the analog inputs you can select each function only once (exception: Uncommitted value).
On the analog outputs also each function can only be selected once (exception: Measurement area; Alarm).
i
Note You can use the analog inputs, outputs and the digital input of the PIF simultaneously.
