Enclosure Installation
2.1 Installing the Enclosures and Touch Screen
The Touch Screen Kiosk, Surface Mount and Flush Mounts units consist of the
following pre-assembled components:
Kiosk. The kiosk is a pedestal mounted Touch Screen TX3-TOUCH-K15-A unit
and consists of the following components:
• Touch Screen Base Plate
• Touch Screen Kiosk
• Touch Screen Panel
• Touch Screen Speakers
• Touch Screen Frame
• Touch Screen Door
Surface Mount. The surface mount unit is a TX3-TOUCH-S15-A or TX3-
TOUCH-S22 unit and consists of the following components:
• Touch Screen Enclosure
• Touch Screen Panel
• Touch Screen Speakers
• Touch Screen Frame
• Touch Screen Door
Flush Mount. The surface mount unit is a TX3-TOUCH-F15-A or TX3-
TOUCH-F22 unit and consists of the following components:
• Touch Screen Enclosure
• Touch Screen Panel
• Touch Screen Speakers
• Touch Screen Frame
• Touch Screen Door
