Chapter 5 Settings
134
5.1 FUNCTION
This features settings for various useful functions and operations when using the machine. Press the
[FUNCTION] key and execute or set the following items:
Item Details Refer to
Square
[SQUARE CUT]
Performs a test cut to confirm that the tool
conditions are appropriate.
• Cuts two squares using test cutting.
"Test Cutting"(P. 72)
DATA CLEAR Clears the data when data cutting has been
aborted.
"Aborting Cutting (Data
Clear)"(P. 74)
FEED Pulls out the sheet before cutting to provide
slack.
• Feed length: 0.1 to 51.0 m
"Sheet Feed"(P. 119)
Multiple sheet
cutting
[No. COPIES]
Cuts multiple copies of the received data.
• Cut copies: 1 to 999 copies
• Interval between images cut: 0 to 30 mm
"Cutting Multiple Copies of the
Same Data [No. COPIES]"(P. 106)
Distance correction
[DIST.COMP.]
When cutting long data, discrepancies in the
displacement may arise between the sheet left
and right sides. This corrects such
discrepancies.
• Standard value:
A direction: 500, 1,000, 1,500, 2,000,
2,500 mm
B direction (CG-60AR): 200, 400, 600 mm
B direction (CG-100AR): 200, 400, 600,
800, 1,000 mm
B direction (CG-130AR): 200, 400, 600,
800, 1,000, 1,200 mm
• Correction value:
A direction: ± 5 % of standard length (0.1
mm steps)
B direction: ± 5 % of standard length
(0.1mm steps)
• Plotting offset: 0 to 300 mm
"Length Correction
[DIST.COMP.]"(P. 103)
Settings
[SET UP]
In this menu, you can make various settings
on the machine.
"SET UP"(P. 135)
MARK SENSOR Checks the responsiveness of the register
mark sensor when data with register marks
was unable to be cut correctly.
"Checking Register Mark Sensor
Responsiveness"(P. 162)
SAMPLE CUT Cuts a sample to troubleshoot problems when
data was unable to be cut correctly.
"Investigating the Cause of
Cutting Failures"(P. 165)
User selection
[USER CHANGE]
Settings (cutting conditions, distance
correction, and main unit settings) can be
saved individually for each user. (Up to 8)
Simply selecting a user number corresponding
to the user allows the machine to be used
without the need to alter any settings.
"Changing Users [USER
CHANGE]"(P. 129)
LIST This can be used as a record by the customer
or for faxing when inquiring about
maintenance.
"Outputting the Settings List
[LIST]"(P. 128)
To Next Page
