9.1 Specifications
Item Details
CG-60AR CG-100AR CG-130AR
Compatible sheet widths 90 to 740 mm
(4 to 28 inches)
90 to 1250 mm
(4 to 48 inches)
90 to 1550 mm
(4 to 60 inches)
Compatible roll
sheet
External
diameter
Max. 150 mm Max. 200 mm
Weight 8 kg or less 20 kg or less
Cutting range
*1
606 mm × 51 m 1,070 mm × 51 m 1,370 mm × 51 m
Maximum
speed
45° direction 103 cm/s
Setting speed
(cutting/printing)
1 to 10 cm/s (1 cm/s steps)
10 to 70 cm/s (5 cm/s steps)
73 cm/s
Mechanical resolution X axis: 2.5 μm, Y axis: 5 μm
Program steps 25, 10 μm (MGL-IIc)
100, 50 μm (MGL-Ic1)
Repetition accuracy
*2
0.2 mm/2 m (excluding elongation due to film moisture)
Accuracy range (Repetition
accuracy)
586 mm × 2 m 1,050 mm × 2 m 1,350 mm × 2 m
Depending on specified film and cutting conditions
Maximum pressure 550 g
Pressure
setting
Cutter 10 to 20 g (in 2 g steps)
20 to 100 g (in 5g steps)
100 to 550 g (in 10g steps)
pen 10 to 20 g (in 2 g steps)
20 to 100 g (in 5g steps)
100 to 150 g (in 10g steps)
Creasing tool
(option)
10 to 20 g (in 2 g steps)
20 to 100 g (in 5g steps)
100 to 550 g (in 10g steps)
Film that can be cut PVC sheet (not more than 0.25 mm thick, including lamination), rubber
sheet, fluorescent sheet
*3
, reflective sheet
*3
, coated card
*4
(using the
optional sheet table)
Usable tools Eccentric cutter, ballpoint pen, commercially available ballpoint pen
(option)
*5
, creasing tool (option)
Command
*6
MGL-IIc, MGL-Ic1
Interface USB, RS-232C, Ethernet
Receive buffer Approx. 27 Mbytes standard (approx. 17 Mbytes with sorting enabled)
Operating conditions 5 °C to 35°C, 35 to 75 % (Rh) with no condensation
