Chapter 1 Before Using This Machine
28
Pinch Rollers and Grit Rollers
The pinch rollers and grit rollers are used to grip and feed the sheet.
For more information, refer to "Moving the Pinch Rollers"(P. 55).
For more information on the settings for the number of pinch rollers, refer to "Setting the Number of Pinch
Rollers to Use"(P. 56).
For more information on the sheet clamping pressure, refer to "Setting the Clamp High/Low
Mode"(P. 57).
SHEET sensor
The sheet sensors detect whether a sheet is present and detects the sheet length.
One sensor is located in front of the platen, and one sensor is located behind the platen.
Clamp
The sheet clamping pressure can be switched between high mode and low mode using the clamp pressure
lever.
Select high or low mode to suit the sheet being used.
For more information, refer to "Setting the Clamp High/Low Mode"(P. 57).
To Next Page
