Chapter 4 Helpful Tips
122
l
OVER CUT
The machine cuts the media in front of the cutting start point by the set value. The media is overcut by the
set value at the end point.
OVER CUT: OFF OVER CUT: 0.1 to 1.0 mm
l
CORNER CUT
When the OVER CUT setting value is entered, CORNER CUT is displayed. The machine performs over
cutting at corners other than the start and end point.
CORNER CUT: OFF CORNER CUT: ON
1
Press the [FUNCTION] key in local mode.
2
Use to select [SET UP], then press the [ENTER/HOLD] key.
3
Use to select [OVER CUT], then press the [ENTER/HOLD] key.
4
Use to select the [OVER CUT] setting, then press the [ENTER/HOLD] key.
Settings: OFF, 0.1 to 1.0 mm (in 0.1 mm increments)
5
Use to select the [CORNER CUT] setting, then press the [ENTER/HOLD] key.
Settings: ON/OFF
6
Press the [END] key several times to exit.
Configuring the Network Settings [NETWORK]
Sets the network address. The machine must be restarted to enable this setting.
Set the following items:
Item
Setting
*1
Details
IP Address - Displays the machine's current IP address.
It may take some time to determine the IP
address. If the IP address cannot be
determined, the display will indicate "0.0.0.0".
MAC Address - Displays the machine's current MAC address.
DHCP ON/OFF Select "ON" to use the IP address assigned by
the DHCP server.
