Chapter 7 Options
154
• Take care not to touch the adhesive surface.
• Retain the separator, as this will be used when storing the cutting sheet.
Adhesive surface
Peel off
Separator
Cutting sheet
3
Affix the sheet to the adhesive surface of the cutting sheet.
• The size of the adhesive surface corresponds to the available cutting area. Affix the sheet so that it
is within the available cutting area.
• When affixing thin sheets, take care to ensure that the sheet does not wrinkle.
• Coated card must be affixed with the non-coated side against the adhesive surface. The
card may become detached if the coated side is affixed or both sides of the card are
coated.
Sheet
Adhesive surface
Cutting sheet
Cutting
Always use three pinch rollers. The middle pinch roller helps to prevent the sheet lifting up.
"Setting the Number of Pinch Rollers to Use"(P. 56) "Enabling and Disabling the center clamp"(P. 57)
1
Move the three pinch rollers respectively to the positions of the grit rollers shown in the figure
below.
2
Push back the clamp lever to raise the pinch rollers.
To Next Page
