MIMAKI CG-AR Series User Manual

Chapter 1 Before Using This Machine
36
1.4 Connecting the Power Cable
1
Check to confirm that the machine power supply is off.
• "Turning Off the Power"(P. 38)
2
Attach the power cable clamp (accessory).
• Insert the power cable clamp into the power cable clamp hole.
• Check that the power cable clamp is securely attached by tugging on it.
Hole
Power cable clamp
3
Plug the power cable into the inlet of the machine.
Inlet
Power cable clamp
4
Slide the power cable clamp out to an appropriate position.
• To slide the power cable clamp out, push up the tab underneath.
• The tab does not need to be pushed up when sliding the power cable clamp in.
Handle
Power cable clamp
