Chapter 2 Cutting
48
9
Press or to select [LEAF].
• "Note about sheet detection"(P. 45)
• : If the sheet was loaded from the rear of the machine
• : If the sheet was loaded from the front of the machine
• Pressing the [FEED] key displays a screen for selecting the number of pinch rollers before
sheet detection. Select the number of pinch rollers before performing sheet detection.
The number of pinch rollers set here takes precedence over the number of pinch rollers
using the [SET UP] - [PINCH ROLL.] menu.
10
Press to select the number of pinch rollers to be used.
• If [ROLL. SELECT] is set to [ON], select the number of pinch rollers to use. "Setting the
Number of Pinch Rollers to Use"(P. 56)
11
Start sheet detection.
• If [DUMMY CUT] is set to [ON], a dummy cut is performed after sheet detection is complete.
"DUMMY CUT"(P. 140)
• Detection is not possible for leaf sheets of 5 m or longer length.
mm display
Sheet detection size display
Current tool conditions
display
Loading a Roll Sheet (CG-60AR)
When using a roll sheet, the roll-placing tables or optional CG-60AR legs must be attached.
l
Attach the roll-placing tables.
1
Insert the roll-placing table into the slot at the rear of the machine.
To Next Page
