Chapter 9 Appendix
175
Item Details
CG-60AR CG-100AR CG-130AR
Power supply capacity 100 to 240 V AC, 140
W to 168 W
100 to 240 V AC, 190 W to 228 W
External
dimensions
Width 1,010 mm 1,510 mm 1,810 mm
Depth 355 mm 580 mm
Height 355 mm 1,160 mm
Weight 17 kg (without legs)
27 kg (with legs: option)
35 kg 43 kg
Noise level
*7
At standby 50 dB (vacuum fan at low speed)
Operating 70 dB (continuous noise)
*1. The software used may include restrictions on the maximum feed length. The maximum feed length may
also be restricted depending on how the sheet is loaded or obstructions at the front or rear. As a guide, set
the maximum feed length to 2 m for one set of data.
*2. For information on repetition accuracy, refer to the next page.
*3. When using fluorescent sheet blade (SPB-0007) or reflective sheet blade (SPB-0006)
*4. Cutting quality and accuracy may be reduced with thick coated card.
*5. Use one 8 to 9 mm in diameter free of protrusions and tapers on the clamped part. The pen nib position
may vary depending on the pen, resulting in reduced image quality.
*6. MGL-IIc ESC. commands cannot be used when using USB or Ethernet.
*7. Values based on Mimaki standard measurements.
9
To Next Page
