Chapter 1 Before Using This Machine
17
It is recommended that the cutter guard be attached if the sheet may be damaged by the cutter due to the
sheet lifting during cutting.
• Turn off the machine power supply before attaching or removing the cutter guard.
• Attaching the cutter guard reduces the size of the gap below the carriage. Remove the cutter
guard if it prevents loading of thick sheets.
l
Attaching the cutter guard
1
Remove the carriage cover.
(1) Remove the screw on the front of the carriage cover.
• Do not to lose this screw.
(2) Lower the carriage cover.
(3) Pull the carriage cover diagonally out toward you, then detach from the lugs.
1
To Next Page
