Chapter 3 Cutting Data with Register Marks
96
5
Use to select the width to be scanned, then press the [ENTER/HOLD] key.
• Setting: 10 to 30 cm
6
Use to select the search range, then press the [ENTER/HOLD] key.
• Setting: 10 to 50cm
7
Press the [END] key several times to exit.
• If marks are not recognized as register marks or if no response is obtained even after scanning
the set search range, the "SEARCH FAILED" message appears for a preset length of time.
The machine then returns to the origin position and switches to normal semi-automatic register
mark detection mode.
To Next Page
