2-8
• When you change the table spacer, the height of the vacuum table changes as below:
• The height of vacuum table is changed as shown below if the table spacers are removed.
• Attach the spacer by rotating by hand without any tool such as a spanner.
When using table spacer 100
When using table spacer 50
100mm 50mm
