13-20 Probes and Biopsy
îš„ NGB-005
îš„ NGB-006
Metal/needle detachable needle-guided bracket:
No. Name Description
<1> Support of needle-guided
bracket
Used for installing the needle-guided bracket on the
probe.
<2> Groove and tab of the
needle-guided bracket
Respectively matched with the tab and groove of the
probe.
<3> Angle adjusting base There are 3 types of angles available to be adjusted.
<4> Angle shift sign
(25°,35°,45°)
Matched with the biopsy angle (25°, 35°, and 45°).
<5> Angle pinch nut Used for fixing the angle block at a chosen angle.
<6> Angle block Used for fixing the angle block at a certain angle.
Probe
Needle-guided
bracket
To Next Page
