Probes and Biopsy 13-25
 NGB-015
 NGB-016
No. Name Description
<1>
Clamp of needle-guided
bracket
Used for installing the needle-guided bracket on the
probe.
<2>
Groove of the
needle-guided bracket
Matches with the tab of the probe.
<3> Angle adjusting base There are 3 types of angles available to be adjusted.
<4>
Angle shift sign (30°, 40°,
50°)
Matches with the biopsy angle. (30°, 40°, 50°).
<5> Angle pinch nut Used for fixing the angle lock at a chosen angle.
<6> Angle block
Determines the angle of the biopsy; different
specifications of blocks can be used.
<7> Guiding block
Used for installing the needles of different
specifications, 5 types of needles are available.
<8>
Specification of guiding
block (14G)
Matched with the corresponding biopsy needle (14G).
<9>
Guiding hole of biopsy
needle
Used for installing the needles.
Lock pin
Needle fixin
g
nut
Needle t
y
pe dial scale
Needle type adjusting base
Groove
Clamp
Pinch nut
A
ngle pinch nut
A
n
g
le shift si
g
n
A
n
g
le ad
j
ustin
g
base
A
n
g
le block
V-shaped cove
r
V-shaped
g
uidin
g
block
Guidin
g
hole
