9−2−7. Selection of output logic for P.C.(Print command), and selection of its width
Selection of the P.C. logic for BCD output, and its width can be made by setting
function. (Related function：F−44, F−45)
Select the P.C. width to meet with the display rate set by F−03, and execute the suitable
selection according to the following list.
Dis
p
la
y
rate
P.C. width
Display
rate
(F−03)
Approx.125 ms Approx.25 ms
4 times/s ○ ○
20 times/s × ○
○：Possible to use, ×：Impossible to use.(P.C. output doesn’t operate correctly.)
Warning ● The selection of P.C. width should be made adequately according to
the display times set with the F−03. If neglected, the P.C. output will
not operate correctly.
