Minebea CSD-701B - 3−3. Installation

IV
(2) Installation
 ● When installing the instrument, install as referring to the following
figures and secure the space around the instrument.
Each dimensions of the instrument and required dimensions for the environmental
spaces are as follows:
Outline dimensions
Panel cut size
Front
Side
Rear
Upper
Unit：mm
