Minebea CSD-701B - Error Display

131
10−3. Error display
Error
code
Contents of error Remedy
ER−0 Zero set has executed with more than
±10 % of the maximum display value.
Apply zero set after making it within ±
10 % of maximum display value.
When CHECK is ON, zero setting is executed. After CHECK is OFF, execute the zero
setting.
ER−1 Setting mistake Set correctly.
ER−2 Mistake in setting during calibration Set correctly.
ER−3 A/D error Turn off the power once and turn on it
again. If the Error is still shown, contact
with Minebea.
ER−4 Displays when the calibration(CCAL, ACAL,
LCAL,TARE) is executed with the CHECK
ON.
After setting the CHECK OFF, execute
the calibration.
ER−5 At the time of fine adjustment on zero or span,
it is shown when tare weight cancellation,
zero set, and zero tracking and peak are ON.
Displays while tare weight cancellation is ON
when zero set is executed.
Set OFF while zero tracking is OFF. And
set OFF while the peak is ON.
Apply ZERO clear(F−98).
ER−6 When prohibiting the calibration is set,
calibration or fine adjustment for analog is
proceeded.
Remove the prohibition of calibration
(F−97).
HOLD Powered ON with the HOLD input is shorted. Set the HOLD input open.
TE−L Displays when the initial value at the time of
calibration is less than −0.3 mV/V, or the
total value with the initial load and the load
equal to the maximum display value is less
than −3.1 mV/V.
Adjust so that the initial load is within
the
range
from
03
mV/V
to
24
mV/V
TE−H Displays when the initial load is more than 2.4
m V/V, or the total value with the initial value
and the load equal to the maximum display
value exceeds 3.1 mV/V during calibration.
t
he
range
f
rom −0.3 mV
/
V to 2.4 mV
/
V.
SP−L The value equal to the maximum display value
at the time of calibration (LCAL) is less than
0.4 mV/V, or the difference between the initial
value and the load equal to the maximum
display value is less than 0.4 mV/V.
Adjust so that the value equal to the
maximum
display
value
is
within
the
SP−H The value equal to the maximum display value
at the time of calibration (LCAL) exceeds 3.1
mV/V, or the difference between the initial
value and the load equal to the maximum
display value exceeds 3.1 mV/V.
max
i
mum
di
sp
l
ay va
l
ue
i
sw
ithi
n
the
range from 0.4 mV/V to 3.1 mV/V.
ER−E EEPROM error
Contact
with
Minebea
ER−R EEPROM error
C
ontact w
i
t
h
Mi
ne
b
ea.
OL Displays when 110 % of the maximum display
value is exceeded at the time of measurement
or in calibration.
Se
t
so tha
t
th
e
load dis
p
la
y
will be within
−OL Displays when −10 % of the maximum
display value is exceeded at the time of
measurement or in calibration.
Set
so
that
the
load
display
will
be
within
the range from −10 % to 110 %.
ER−W RAM error Contact with Minebea.
