9−7. Power supply voltage DC24 V(CSD701B−P67)
9−7−1. Layout of the terminal boards
There is one terminal board containing 21 point of terminals in the panel.
Layout of terminal boards when the power supply voltage is DC24 V are shown in the following
figure.：
1
Terminal board（21P）
Terminal
No.
Descriptions Applications
Terminal
No.
Descriptions Applications
1 A 11
PEAK/TRACK
or A/Z
External control
2 B
Strain gage
li d
d
12
RESET or A/Z
OFF
External
control
input
3 C
gg
applied transducer
13 COM.2
4 D 14 S1
Contact output
5 E 15 S2
p
6 A−OUT ＋ 16 F. G Frame ground
7 A−OUT −
Analog output
17 SOURCE
DC0 V power
supply
8 COM.1 18 N.C.
9 ZERO
External control
input
19 SOURCE
DC＋24 V power
supply
10 HOLD
p
20 N.C.
21 Ground
 ● The COM.1(Terminal No.8) and COM.2(Terminal No.13) are isolated.
● Please refer to clause 4−2 for notes concerning connecting wires.
● The power supply is DC24 V(DC20 V to DC30 V).
